Unisorb — Foundation Isolation
Regufoam™ Isolation Material: Regufoam™ is applied as a vibration isolating structural element in the installation of both source and sensitive equipment. Regufoam installations provide a cost effective and simple approach to preventing the transmission of structure borne noise and vibration. Regufoam™ is an engineered combination closed and open cell foam material that exhibits excellent vibration isolation characteristics including exceptional damping and superior durability in the industrial/commercial environment as proven in over two decades of successful applications.
Models: Regufoam150, Regufoam220, Regufoam300, Regufoam400
Contact Acorn™ for more information or to place an order.
GK™ Low Frequency Foundation Blocks: The GK™ Low Frequency Foundation Block is specifically used for isolating equipment where low interfering frequencies are encountered. They are typically used under concrete foundations supporting either source or sensitive machines. The highly specialized rubber compounds used, unique geometrical shape and carefully controlled load deflection characteristics make the GK block an excellent lower cost alternative to installations normally required to reach system natural frequencies as low as 4 Hz. GK™ Blocks are available in load ratings from 4,000 to 18,000 lbs.
Contact Acorn™ for more information or to place an order.
RD™ Isolation System: The RD™ Isolation System offers natural frequencies down to 1.5 Hz, is cast into concrete inertia block, uses variable and replaceable isolator units, simplifies construction, and can be leveled after construction.
Contact Acorn™ for more information or to place an order.
IB-500™ Inertia Block Foundation Isolation Materials: UNISORB® IB-500™ Inertia Block Isolation Materials offer superior performance because they have been specifically engineered to provide optimum compression rates for the inertia block while using standard foundation construction techniques. These products are unaffected by oils, coolants, cutting fluids and other liquids normally found in the industrial environment. IB-500™ Inertia Block Isolation Materials are conservatively rated, providing a life expectancy which typically exceeds that of the machinery being installed.
The materials are manufactured in two densities: A less dense material, designated IB-500-S2, is used to isolate sidewalls of the inertia block; A more dense material, IB-500-B1, is applied to the base surface of the foundation (usually two layers). Both materials are manufactured in 1/2" thick sheets and are used in layers where greater thickness is desired. The material is available from stock in 3' x 6' sheets for fast delivery. Special sizes may be cut to exact dimensions at the factory or on the job site.
Contact Acorn™ for more information or to place an order.
In-Plant Surveys / Demonstrations / Quotes
Contact Acorn™ today for an in-plant survey, product selection / demonstration, application assistance or to request a quote.
Regufoam™ Isolation Material: Regufoam™ is applied as a vibration isolating structural element in the installation of both source and sensitive equipment. Regufoam installations provide a cost effective and simple approach to preventing the transmission of structure borne noise and vibration. Regufoam™ is an engineered combination closed and open cell foam material that exhibits excellent vibration isolation characteristics including exceptional damping and superior durability in the industrial/commercial environment as proven in over two decades of successful applications.
Models: Regufoam150, Regufoam220, Regufoam300, Regufoam400
Contact Acorn™ for more information or to place an order.
GK™ Low Frequency Foundation Blocks: The GK™ Low Frequency Foundation Block is specifically used for isolating equipment where low interfering frequencies are encountered. They are typically used under concrete foundations supporting either source or sensitive machines. The highly specialized rubber compounds used, unique geometrical shape and carefully controlled load deflection characteristics make the GK block an excellent lower cost alternative to installations normally required to reach system natural frequencies as low as 4 Hz. GK™ Blocks are available in load ratings from 4,000 to 18,000 lbs.
Contact Acorn™ for more information or to place an order.
RD™ Isolation System: The RD™ Isolation System offers natural frequencies down to 1.5 Hz, is cast into concrete inertia block, uses variable and replaceable isolator units, simplifies construction, and can be leveled after construction.
Contact Acorn™ for more information or to place an order.
IB-500™ Inertia Block Foundation Isolation Materials: UNISORB® IB-500™ Inertia Block Isolation Materials offer superior performance because they have been specifically engineered to provide optimum compression rates for the inertia block while using standard foundation construction techniques. These products are unaffected by oils, coolants, cutting fluids and other liquids normally found in the industrial environment. IB-500™ Inertia Block Isolation Materials are conservatively rated, providing a life expectancy which typically exceeds that of the machinery being installed.
The materials are manufactured in two densities: A less dense material, designated IB-500-S2, is used to isolate sidewalls of the inertia block; A more dense material, IB-500-B1, is applied to the base surface of the foundation (usually two layers). Both materials are manufactured in 1/2" thick sheets and are used in layers where greater thickness is desired. The material is available from stock in 3' x 6' sheets for fast delivery. Special sizes may be cut to exact dimensions at the factory or on the job site.
Contact Acorn™ for more information or to place an order.
In-Plant Surveys / Demonstrations / Quotes
Contact Acorn™ today for an in-plant survey, product selection / demonstration, application assistance or to request a quote.
