Vector® Bolts: Made from high quality forged steel, VECTOR® Bolts have a series of angular facets which resolve vertical stress forces into a cone-shaped pressure pattern. An advantage of this unique design is the increased contact area between the bolt and the grout. The wedge shaped design on the bottom of the bolt transfers the tensile load of the stud into a lateral compressional load in the foundation, assuring maximum pull out strengths. VECTOR® Bolts are available in several metric diameters and lengths in a 90,000 psi minimum tensile strength material.
Contact Acorn™ for more information or to place an order.

Heavy Duty Jakebolts® Bolts: Constructed entirely of steel, the Heavy Duty JAKEBOLTS® are tough, durable, and MIG welded watertight to prevent contamination of internal components during installation. Each JAKEBOLT® comes supplied with a centralizing bushing which doubles as a seal and protects against contamination during grouting. Anchor studs can be adjusted to project above the floor from 0 to 6" or 0 to 12", depending on the bolt specified for the installation. The entire internal anchor assembly can be adjusted laterally as well as vertically to compensate for normal construction variances in both hole location and machine foot thickness. The Heavy Duty JAKEBOLT® incorporates 90,000 psi tensile strength steel in the bolts. The all steel anchor assembly is designed for service under the most severe conditions.
Contact Acorn™ for more information or to place an order.

Capsule Anchor System™: UNISORB® Capsule Anchors™ offer tremendous holding power which is stronger than the concrete itself. A graded blend of quartz aggregate transfers the pullout forces into the concrete. Since there are no expansive forces from the anchors, they can be placed near foundation edges, chip troughs, coolant trenches or wireways. High anchor to concrete strengths are developed, allowing smaller anchor holes and studs than what is possible with conventional expanding anchor type systems. UNISORB® Capsule Anchors™ are ideal for anchoring the following equipment:

• Air conditioners • Printing presses • Machine tools • Motors • Robots

• Conveyors • Refrigeration equipment • Presses • Hand rails • Crane rails

• Grinders • Compressors • Pumps • Jib cranes

Contact Acorn™ for more information or to place an order.

Fixator® Systems:  Machine tools installed and aligned on UNISORB® FIXATOR® Anchoring and Alignment Systems operate at maximum design efficiency. UNISORB® FIXATOR® Systems have been carefully designed to provide optimum performance and ease of installation, even in the most demanding of circumstances.
RK™ Fixator® System: Makes support critical machinery installations fast and easy. The most rigid machine to foundation connection available.
AKII™ Agile® Fixator® System: Intended for use in anchorless or anchored applications and offers the capability to be quickly converted from one to the other without disturbing or removing the machine base.
DS™ Fixator® System: A free standing leveling jack for machinery that requires a large leveling range.
MS™ Fixator® System: For vertical and lateral alignment and anchoring of electric motors, pumps, compressors, and other applications.
S™ FIXATOR® System: Complements the RK™ FIXATOR® System, ideal for floor plates where leveling must be accomplished from above.
Contact Acorn™ for more information or to place an order.

Downloads
Unisorb® Anchors PDF (Technical Data - All Types, Vector Bolts, All Steel Jakebolts, Capsule Anchors)
Unisorb® Fixators PDF (RK Fixator Systems, AK Fixator Systems, DS Fixator Systems, MS Fixator Systems, LK Fixator Systems, S Fixator Systems)

In-Plant Surveys / Demonstrations / Quotes
Contact Acorn™ today for an in-plant survey, product selection / demonstration, application assistance or to request a quote.
