RÄDER-VOGEL® Casters
Since 1946, RÄDER-VOGEL® has been producing castors that prove to be of superior quality in industrial applications. Strict checks in all stages of production and intensive product testing under arduous conditions guarantee the high quality of their products now and in future. Acorn™ offers a wide variety of RÄDER-VOGEL® casters to fit your specific need.
Click on the links below to quickly scroll down the page:
Stainless Steel Casters
• Capacity to 400 kg (880 lbs)
• Capacity to 750 kg (1650 lbs)
Pressed Steel Casters
• Capacity to 400 kg (880 lbs)
• Capacity to 750 kg (1650 lbs)
• Capacity to 1000 kg (2200 lbs)
VL Series
VFL Series
VB Series
|
Series VL / VLF / VB
Capacity to 400 kg (880 lbs)
Housings made of strong, pressed stainless steel. Swivel head with double ball bearings, dust and splash proof. Riveted kingpin. ALLSTOP total locking device on the trailing side of the housing, locks rolling and swivel motion at the same time.
PEVOLON® wheels have a high abrasion resistance, low coefficient of friction, a high load capacity and a long service life.
• Series VL Swivel Caster
• Series VLF Swivel Caster with ALLSTOP total locking device
• Series VB Rigid Caster
Download VL / VLF / VB PDF |
Back to Top
Capacity to 750 kg (1650 lbs)
Housings made of
strong, pressed stainless steel. Swivel head with double ball bearings, dust and splash proof. Kingpinless with grease nipple. ALLSTOP total locking device on the trailing side of the housing, locks rolling and swivel motion at the same time.
Stainless Steel Casters with the capacity of 750 kg (1650 lbs) include:
WL/NI Series
Swivel Caster
WLF/NI Series Swivel Caster with ALLSTOP total
locking device
WB/NI Series
Rigid Caster
|
Series WLNI / WLFNI / WBNI (shown left)
PEVOLON® wheels have a high abrasion resistance, low coefficient of friction, a high load capacity and a long service life.
Download WLNI / WLFNI / WBNI PDF
Series WL PU/NI, WLF PU/NI and WB PU/NI
PEVOTHAN® is a high quality thermoplastic polyurethane (TPU) elastomer. Among its outstanding properties are high load capacity, non-marking, high abrasion resistance and good dampening values. PEVOTHAN® is normally resistant to diluted acids and caustic solutions as well as mineral greases and oils. Its temperature resistant ranges from -20°C to +80°C (-4°F to +176°F). Due to its excellent physical, thermal and chemical characteristics, PEVOTHAN® is superior to any standard rubber wheel and consequently recommended for sensitive floor conditions.
Download WL PU/NI, WLF PU/NI, WB PU/NI PDF |
Back to Top
Capacity to 400 kg (880 lbs)
Housings made of pressed steel, zinced and chromated. Swivel head with double ball bearings, dust and splash proof. Riveted kingpin. Standard type with top plate. ALLSTOP total locking device on the trailing side of the housing, locks rolling and swivel motion at the same time.
Pressed Steel Casters with the capacity of 400 kg (880 lbs) include:
41 PUR Series
Swivel Caster
41 F PUR Series
Swivel Caster with ALLSTOP total
locking device
42 PUR Series
Rigid Caster
|
Series 41 PUR / 41 F PUR / 42 PUR (shown left)
PEVOPUR® wheels have outstanding mechanical and chemical characteristics: high dynamic load capacity, high elasticity, good compression set and resistance to a multitude of chemical media.
Series 41 PUR / 42 PUR PDF
Series PL / PB
PEVOLON® wheels are non-marking and are characterized by high abrasion resitance, low rolling resistance and high load capacities. Due to their high melting point, constant operating temperatures of about 80-90°C (176-194°F) do not cause any material deformation.
Series PL / PB PDF
Series PL BPU / PB BPU
PEVOLASTIC® wheels consist of a PEVOLON® core with a chemically bonded non-detachable tread of polyurethane (Desmopon® of Bayer AG, Leverkusen). PEVOLASTIC® wheels are elastic and several times more resistant to abrasion than rubber and withstand most chemical media. The temperature resistance ranges from -20°C to +80°C (68°F to 176°F).
Series PL BPU / PB BPU PDF
Series 31 PU / 32 PU / 51 PU / 52 PU
PEVOTHAN® is a high quality thermoplastic polyurethane (TPU) elastomer. Among its outstanding properties are high load capacity, non-marking, high abrasion resistance and good dampening values. PEVOTHAN® is normally resistant to diluted acids and caustic solutions as well as mineral greases and oils. Its temperature resistant ranges from -20°C to +80°C (-4°F to +176°F). Due to its excellent physical, thermal and chemical characteristics, PEVOTHAN® is superior to any standard rubber wheel and consequently recommended for sensitive floor conditions.
Series 31 PU / 32 PU / 51 PU / 52 PU PDF
Series 23 / 24 / 27 / 28
ELASTIC SOLID RUBBER Wheels have an especially high load capacity due to their special rubber compound. The tIres are floor-saving and characterized by a very low rolling resistance, excellent operational comfort as well as a high wear resistance. The firm tIre seat on the wheel center is attained by vulcanizing the tires on onto the wheel center. Operating temperature: -30° C to +80° C, (Temporarily up to +100° C ). Increased ambient temperature in combination with high loads and speed may lead to an overheating of the tire.
Series 27 / 28 PDF
Series 23 / 24 PDF |
Back to Top
Capacity to 750 kg (1650 lbs)
Housings made of pressed steel, zinced and chromated. Swivel head with double ball bearings, dust and splash proof. Without kingpin. With grease nipple. ALLSTOP total locking device on the trailing side of the housing, locks rolling and swivel motion at the same time.
Pressed Steel Casters with the capacity of 750 kg (1650 lbs) include:
WL Series
Swivel Caster
WLF Series
Swivel Caster with ALLSTOP total
locking device
WB Series
Rigid Caster
|
Series WL / WLF / WB (shown left)
PEVOLON® wheels are non-marking and are characterized by high abrasion resitance, low rolling resistance and high load capacities. Due to their high melting point, constant operating temperatures of about 80-90°C (176-194°F) do not cause any material deformation.
Series WL / WLF / WB PDF
Series WL PU / WLF PU / WB PU
PEVOTHAN® is a high quality thermoplastic polyurethane (TPU) elastomer. Among its outstanding properties are high load capacity, non-marking, high abrasion resistance and good dampening values. PEVOTHAN® is normally resistant to diluted acids and caustic solutions as well as mineral greases and oils. Its temperature resistant ranges from -20°C to +80°C (-4°F to +176°F). Due to its excellent physical, thermal and chemical characteristics, PEVOTHAN® is superior to any standard rubber wheel and consequently recommended for sensitive floor conditions.
Series WL PU / WLF PU / WB PU PDF
Series 25 / 26
ELASTIC SOLID RUBBER Wheels have an especially high load capacity due to their special rubber compound. The tIres are floor-saving and characterized by a very low rolling resistance, excellent operational comfort as well as a high wear resistance. The firm tIre seat on the wheel center is attained by vulcanizing the tires on onto the wheel center. Operating temperature: -30° C to +80° C, (Temporarily up to +100° C ). Increased ambient temperature in combination with high loads and speed may lead to an overheating of the tire.
Series 25 / 26 PDF
Series 203 / 204
PEVOSOFT® wheels are a high-quality polyurethane elastomer suited for all applications where better noise and vibration dampening, high-drive comfort, floor protection or general transport is required. For example, transport of sensitive goods. Among the excellent mechanical and chemical properties are high-dynamic load capacity, high elasticity, good compression set behaviors, resistant to a multitude of chemical agents, high abrasion and cut and tearing resistance. Compared to rubber, the load capacity of PEVOSOFT® is many times higher and is non-marking.
Series 203 / 204 PDF
Series 217 ALU PUR / 217 PUR and
218 ALU PUR / 218 PUR
PEVOPUR® wheels have outstanding mechanical and chemical characteristics: high dynamic load capacity, high elasticity, good compression set and resistance to a multitude of chemical media
Series 217 / 218 PDF |
Back to Top
Capacity to 1000 kg (2200 lbs)
Housings made of extra strong pressed steel, zinced and chromated. Swivel head with double ball bearing. Bearing shells of hardened steel. Kingpin bolted and secured. ALLSTOP total locking device on the trailing side of the housing, locks rolling and swivel motion at the same time.
Pressed Steel Casters with the capacity of 1000 kg (2200 lbs) include:
223 PUR Series
Swivel Caster
223 F PUR Series
Swivel Caster with ALLSTOP total
locking device
224 PUR Series
Rigid Caster
|
Series 223 PUR/ 224 PUR (shown left)
PEVOPUR® wheels have outstanding mechanical and chemical characteristics: high dynamic load capacity, high elasticity, good compression set and resistance to a multitude of chemical media.
Series 223 PUR / 224 PUR PDF |
Back to Top
In-Plant Caster & Wheel Survey
Click here to download the Acorn™ In-Plant Caster & Wheel Survey PDF or Contact Acorn™ for additional information.
Learn more about the Benefits of an In-Plant Survey.
Demonstrations / Quotes
Contact Acorn™ today for product selection / demonstration, application assistance or to request a quote.
